Hoover U6003 Dial-A-Matic with Power Drive Upright Vacuum

Quick Links

What's Popular

You are here: Home > HOOVER > HOOVER PARTS & SCHEMATICS BY MODEL > Upright Vacuum Parts (U Series)
> U6003 - Dial-A-Matic with Power Drive Upright

We found 19 results matching your criteria.

Hoover U6003 Dial-A-Matic with Power Drive Upright Vacuum Parts List & Schematic

Item	Part Number
Agitator	Part No Longer Available
1. Thread Guard	12985AY
2. Clip (2)	Part No Longer Available
3. Felt Washer (2)	Part No Longer Available
4. Agitator Bearing Assembly (2) (Use With Ltems 2, 3)	12978
4. Agitator Bearing Assembly (2) (Current)	43267002
5. Rubber Thrust Washer	17396
6. Agitator End Pulley	Part No Longer Available
7. Agitator Shaft	Part No Longer Available
8. Agitator Brush - Reverse Helix (2)	160646BZ
9. Agitator End	160542
10. Thrust Washer	21347003
11. Belt	12471AG
Agitator Brush	160646BZ

Item	Part Number
1. Tool Storage Rack	Part No Longer Available
2. Hose Connector	12593JM
3. Hose Connector Collar	Part No Longer Available
4. Hose Sleeve	32156010
5. Hose (Without Suction Regulator)	Part No Longer Available
6. Hose Storage Loop	Part No Longer Available
7. Hose Connector Collar	36116006
8. Hose Grip	43466044
9. Suction Control Ring	38711006
10. Hose Connector Label	Part No Longer Available
11. Latch Ring	36153009
12. Hose - U5909	Part No Longer Available
12. Hose (Without Suction Regulator)	Part No Longer Available
13. Dusting Brush	161851JM
13. Dusting Brush (One Piece)	43414064
14. Brush (Use With Part Number 61851Jm)	Part No Longer Available
15. Furniture Nozzle	43414057
16. Floor Brush Swivel & Collar (Use With Part Number 13077Jm)	13154JM
16. Swivel Connector (Use With Part Number 43414073)	38644040
17. Floor Brush Swivel Bushing (Use With Part Number 13154Jm)	Part No Longer Available
Split Ring (Use With Part Number 38644040)	33712007
18. Floor Brush	Part No Longer Available
18. Floor Brush	43414073
19. Floor Brush Nozzle & Brush	13155JM
20. Crevice Tool	38617017
21. Extension Tube	43453027
22. Extension Tube - Curved	43466040
23. Gasket	Part No Longer Available
24. Tube Latch	12846AG
25. Rivet	Part No Longer Available
26. Rivet	Part No Longer Available
27. Rivet	12763AW
28. Reinforcement Plate	Part No Longer Available
29. Rivet	12600
30. Washer	21312704
31. Tube Latch - Outer	Part No Longer Available
32. Extension Tube - Outer	Part No Longer Available
33. Extension Tube Guide	12589
34. Gasket - Inner	Part No Longer Available
35. Extension Tube - Inner	Part No Longer Available
36. Extension Tube	Part No Longer Available
37. Hose Grip Collar	12704BZ
38. Hose Tube Curved	Part No Longer Available
39. Hose - 1121, 1131	Part No Longer Available
Cleaning Tool Bag	Part No Longer Available
Ultraflex Hose - 50' Length	Part No Longer Available
Tufflex Hose - 50' Length	Part No Longer Available
Furniture Brush - Ag	Part No Longer Available

Item	Part Number
Handle Cap - 1170, 1176, 1178, U6003, U6007	Part No Longer Available
Handle Cap - U6003-001, U6039, U6039-030, U6041, U6049	Part No Longer Available
Handle Cap	Part No Longer Available
2. Screw	Part No Longer Available
3. Handle Grip	160152KD
3. Handle Grip	48663159
3. Handle Grip	160152DS
3. Handle Grip	160152JX
4. Switch Insulating Sleeve	Part No Longer Available
5. Wire Nut	48969
6. Insulating Pod (2)	Part No Longer Available
Switch	Part No Longer Available
8. Switch Cover Plate - 1178	Part No Longer Available
8. Switch Cover Plate - U6003, U6007	Part No Longer Available
8. Switch Cover Plate	Part No Longer Available
9. Screw (2)	21465314
10. Terminal (2)	Part No Longer Available
11. Retainer	Part No Longer Available
12. Service Plug	Part No Longer Available
13. Cord - 1170, 1176, 1178, U6003, U6003-001, U6041, U6049	Part No Longer Available
13. Cord - U6007, U6039, U6039-030	46383068
14. Cord Protector	Part No Longer Available
15. Handle Tube	Part No Longer Available
16. Tension Wire	Part No Longer Available
17. Handle Support	160094JM
18. Screw - Special	18805
19. Handle Bolt Nut	19462

Item	Part Number
1. Nameplate	52115008
2. Main Casting - 1170, 1176	Part No Longer Available
2. Main Casting - U6041	Part No Longer Available
2. Main Casting	Part No Longer Available
2. Main Casting	Part No Longer Available
3. Rivet (6)	12997AW
4. Rivet (2)	Part No Longer Available
5. Clamp Spring (2)	Part No Longer Available
6. Rivet (2)	Part No Longer Available
7. Upper Pulley Seal	12173
8. Screw (2)	Part No Longer Available
9. Latch L.H.	Part No Longer Available
10. Latch R.H.	Part No Longer Available
11. Hose Adapter	Part No Longer Available
12. Dash Pot Spring	160146
13. Bellows Bracket	Part No Longer Available
14. Trunnion Bearing	160069
15. Washer (4)	Part No Longer Available
16. Screw (4)	12146
17. Power Belt	160147AG
18. Frame - L.H. - 1178, U6003, U6003-001, U6007, U6039, U6039-030, U6041, U6049	Part No Longer Available
18. Frame - L.H. - 1170, 1176	Part No Longer Available
19. Screw (5)	Part No Longer Available
20. Bearing Half (2)	Part No Longer Available
21. Handle Control Spring	Part No Longer Available
22. Screw	Part No Longer Available
23. Handle Control Lever - 1170, 1176	Part No Longer Available
23. Handle Control Lever - 1178, U6003, U6003-001, U6007, U6039, U6039-030, U6041, U6049	163347JM
24. Foot Pad	Part No Longer Available
25. Lock Ring (4)	Part No Longer Available
26. Rear Wheel	Part No Longer Available
26. Caster Wheel (2) - 1170, 1176	32175003
27. Lower Pulley Seal	Part No Longer Available
28. Washer (2)	21312772
29. Hex Nut	Part No Longer Available
30. Drive Wheel	163340AG
30. Drive Wheel - 1170, 1176	160155AG
31. Power Unit	43124010
32. Cleaner Bottom Plate	Part No Longer Available
33. Bottom Plate Gasket	Part No Longer Available
33. Bottom Plate Gasket - U6049	Part No Longer Available
34. Frame R.H. - 1178, U6003, U6003-001, U6007, U6039, U6039-030, U6041, U6049	163333AY
34. Frame R.H. - 1170, 1176	Part No Longer Available
35. Rear Wheel Shaft	Part No Longer Available
36. Bearing	Part No Longer Available
37. Furniture Guard	Part No Longer Available
Nut (Power Drive Unit)	160031

Item	Part Number
1. Motor	Part No Longer Available
Field Lamination Bolt (2)	Part No Longer Available
2. Screw (2)	Part No Longer Available
3. Not Applicable	Part No Longer Available
4. Motor Brush Retainer	Part No Longer Available
5. Motor Brush (2)	Part No Longer Available
6. Motor Brush Holder (2)	Part No Longer Available
7. Insulating Pod (2)	Part No Longer Available
8. Field Assembly	Part No Longer Available
9. Spring (2)	12854
10. Motor Casing	Part No Longer Available
11. Pin (3)	12007
12. Nut Special (2)	Part No Longer Available
13. Armature	Part No Longer Available
14. Fan Spacer	Part No Longer Available
15. Fan (2)	43566003
16. Washer (3)	Part No Longer Available
17. Fan Spacer	Part No Longer Available
18. Lnterstage Assembly	Part No Longer Available
19. Motor Mount - R.H.	12089
20. Motor End Cap & Bearing Assembly	Part No Longer Available
21. Not Applicable	Part No Longer Available
22. Fan Nut	Part No Longer Available
23. Motor Bearing Housing & Bearing Assembly	Part No Longer Available
24. Motor Bearing Retainer	Part No Longer Available
25. Motor Mount - L.H.	Part No Longer Available
26. Nut 12009AY	Part No Longer Available
Motor Gasket	12154

Item	Part Number
1. Dirt Finder Lens - 1176, 1178, U6007, U6039, U6039-030, U6041	162226CP
2. Indicator Lens - 1176, 1178, U6007, U6039, U6039-030, U6041	Part No Longer Available
3. Exhaust Cover - U6039, U6039-030, U6041	Part No Longer Available
3. Exhaust Cover - 1178, U6007	Part No Longer Available
3. Exhaust Cover - U6003, U6003-001	Part No Longer Available
3. Exhaust Cover - U6049	Part No Longer Available
3. Exhaust Cover - 1170	Part No Longer Available
3. Exhaust Cover - 1176	Part No Longer Available
4. Diffuser	12358
5. Full Bag Indicator - 1176, 1178, U6007, U6039, U6039-030, U6041	Part No Longer Available
5. Full Bag Indicator	Part No Longer Available
6. Muffler (3)	161334
7. Screw (3)	Part No Longer Available
8. Clamp (2)	12910
9. Cable Tube	Part No Longer Available
10. Lead Wire	Part No Longer Available
11. Terminal (3)	Part No Longer Available
12. Bag Housing - Front Half - 1170, U6003	Part No Longer Available
12. Bag Housing - Front Half	Part No Longer Available
13. Latch Cover	162008JM
14. Screw	162007
15. Screw - (13) - 1170, U6003, U6003-001, U6049, (14) - 1176, 1178, U6007, U6039, U6039-030, U6041	21447003
16. Bushing	160110BZ
17. Pin	Part No Longer Available
18. Balance Spring - 1178, U6003, U6003-001, U6007, U6039, U6039-030, U6041, U6049	Part No Longer Available
19. Balance Spring - 1170, 1176	Part No Longer Available
19. Retaining Ring	160017
20. Filter Retainer	12121
21. Filter	Part No Longer Available
22. Gasket	12155
23. Secondary Filter Gasket	12156
24. Upper Motor Gasket	12160
25. Motor Support Bracket	12119
26. Screw	12146
27. Screw (3)	Part No Longer Available
28. Muffler	12662
29. Throw Away Bag - 3 Pack	4010005D
30. Throw Away Bag - 9 Pack	Part No Longer Available
Valve Cover	Part No Longer Available
31. Gasket	Part No Longer Available
32. Valve	Part No Longer Available
33. Side Valve Seal (2)	Part No Longer Available
34. Rear Bag Housing	Part No Longer Available
35. Washer	Part No Longer Available
36. Hose Connector Lock	Part No Longer Available
37. Valve Knob	Part No Longer Available
38. Capsert (5)	Part No Longer Available
39. Hinge Shaft Plate (2)	Part No Longer Available
40. Bottom Seal	Part No Longer Available
41. Screw (3)	Part No Longer Available
42. Seal	Part No Longer Available
43. Hose End	Part No Longer Available
44. Hose	43431058
45. Screw (2)	Part No Longer Available
46. Motor Cover	160169JM
47. Lower Motor Gasket	Part No Longer Available
48. Alignment Ring	Part No Longer Available
49. Motor Gasket	12154
50. Nut	Part No Longer Available
51. Spring Washer	19555
52. Insulating Pod (2)	Part No Longer Available
53. Air Seal	Part No Longer Available
54. Lens Seal	Part No Longer Available
55. Pivot Bearing	Part No Longer Available
56. Bolt	Part No Longer Available
57. Hinge Shaft	Part No Longer Available
Rivet (2) -	Part No Longer Available
58. Strain Relief	Part No Longer Available
59. Dirt Finder Lamp - 1176, 1178, U6007, U6039, U6039-030, U6041	27317307
60. Light Socket - 1176, 1178, U6007, U6039, U6039-030, U6041	Part No Longer Available
61. Air Director Plate - 1176, 1178, U6007, U6039, U6039-030, U6041	Part No Longer Available
62. Clamp (2)	Part No Longer Available
63. Exhaust Cover Seal	Part No Longer Available
64. Clip (2)	Part No Longer Available
65. Connector (2) - 1176, 1178, U6007, U6039, U6039-030, U6041	12227
66. Control Cable	Part No Longer Available
67. Nut	21641623
68. Washer (2)	Part No Longer Available
69. Actuator Bar	Part No Longer Available

Sort By:

Furniture Nozzle With Litter Picker 43414057

Hoover Agitator Bearing 43267002

List Price: $10.99

Our Price: $9.75

Sale Price: $8.25

You save $2.74!

List Price: $6.49

Our Price: $5.99

Sale Price: $5.25

You save $1.24!

Furniture Nozzle with litter picker sub 40-1705-08 Hoover Agitator Bearing. Genuine Hoover Vacuum Part. 43267002

Hoover Collar Hose Connector

Hoover Commercial Vacuum Screw

Our Price: $1.17

Our Price: $1.49

Sale Price: $0.99

You save $0.50!

Hoover Collar Hose Connector Hoover Commercial Vacuum Screw . Genuine Hoover Vacuum Part.

Hoover Dusting Brush | 43414064

Hoover Fan Dialamatic Slimline 7/16 Hole

List Price: $15.99

Our Price: $14.00

Sale Price: $12.75

You save $3.24!

Our Price: $5.02

Hoover Vacuum Cleaner Dusting Brush with lock pin. Fits on all Hoover canisters which have attachments that fit inside the wands. It has a pin on the top of the connector to lock it into place. This dusting brush is square and measures 2 7/8 inches wide. Genuine Hoover vacuum part.43414064,H-43414064 Hoover Fan Dialamatic Slimline 7/16 Hole

Hoover Floor Brush With Swivel Neck | Gray 440009293

Hoover Grip Handle U1170

List Price: $18.99

Our Price: $16.00

Sale Price: $14.25

You save $4.74!

Our Price: $11.74

Black Hoover canister vacuum cleaner floor brush fits on all Hoover canisters which have attachments that fit inside the wands. It has a pin on the top of the connector to lock it into place. This floor brush has a swivel neck and is 9 inches wide and 2 inches deep, with three nylon brush strips. Comes standard with most Hoover canister vacuums. Genuine Hoover vacuum cleaner attachment. Hoover Grip Handle U1170

Hoover Hose Sleeve Insert

Hoover Power Drive Unit Dialamatic

Our Price: $1.17

Our Price: $124.46

Hoover Hose Sleeve Insert
THIS ITEM IS NO LONGER AVAILABLE Hoover Power Drive Unit Dialamatic

HOOVER SPLIT RING

Hoover Sprint Crevice Tool | 38617017

Our Price: $1.50

List Price: $6.99

Our Price: $6.10

Sale Price: $5.75

You save $1.24!

HOOVER SPLIT RING 8.5" Black Crevice Tool with Locking Pin 8 1/2" black crevice tool fits on Hoover canisters which use attachments with a pin on the connector which fits INSIDE the hoses or wands. It is not for use on Hoover uprights nor Hoover Bagless canisters since their attachments fit OVER the wands. Model #: 38617017 See prt. # 38617023 for crevice tool that fits Hoover uprights.
