Eureka 2565 - Atlantis Upright Extractor

01. Recovery Tank Assembly - Pkgd 38743-119N
02. Basket - Float 27866A-119N
03. Shampooer Filter 60207
04. Recovery Tank Assembly - Pkgd 15309A-324N
05. Hardware Package 59052
06. Owner's Guide 70326
07. Recovery Tank Assembly 60205
08. Carpet & Upholstery Shampoo 64 60170
09. Instructional Video 70351
Eureka 2565 - Atlantis Upright Extractor

01. Wire Splice 5 60192-1
02. Motor Assembly 60218B
03. FNLA FNLA
04. Base/Support Kit 59516
05. Spring Pkg 5 60217
06. Motor Support--2585At 28142B
07. Screw Pkg 53238-8
09. Switch-Micro 28019A-1
10. Wheel-Rear 27843A-119N
11. Axle 38392
12. Base Assembly. 60624A
13. Nozzle 39290
15. Screw Pkg 53238-27
16. Pump & Motor Assembly 60221C
17. Water Duct Assembly. 38865
18. Prg Lk Rtnr-Pkg 54709
22. Belt Pkg 60129
24. Cover Belt 38738B-119N
25. Screw Package 54669-3
Eureka 2565 - Atlantis Upright Extractor

01. Tank Cap 38735-119N
02. Screw Pkg 53238-27
03. Cover Motor 15316A-119N
04. Screw Pkg 53238-27
05. Axle 38737-119N
06. Screw Pkg 53238-27
07. Cover - Axle 38861-119N
08. Hood & Graphics Assembly - Pk 60223-7
09. Screw Pkg 60224
10. Suction Cover 60204B
11. Dispensing Tank/2585At 60622-1
12. Shroud & Graphics Assembly - 60226-8
13. Screw Pkg 53238-27
14. Seal - Gasket 59025-1
15. Screw Pkg 60227
Eureka 2565 - Atlantis Upright Extractor

01. Handle Assembly. 15394D
02. Switch - Rocker 36052-3
04. Screw Pkg 53238-27
05. Rear Housing Assembly 02191C-119N
06. Tubing 59472-6
08. Supply Cord 38752-119N
09. Trigger Dispenser 27776C-288N
10. Screws Pkg 10 53197-3
11. Upper Arm 27769-119N
12. Actuator-Plunger 38945B-305N
13. Shampooer Filter 60207
14. Boot Seal 38845-119N
15. Screw Pkg 53238-27
16. Housing Cover 28431-1
17. Reservoir Assembly. 38941G
18. Lower Arm 27846B-119N
19. Spring Pkg 60219
xx. Warp - Cord 38836-119N
xx. Tubing 70316-1
